RT crashes when trying to open processing queue

RT https://filebin.net/wmq3x8vc2naysi8b/RawTherapee_OSX_10.9_64_5.3-577-g6567380f.zip

Hi Hiram

I have now tried RT ver 5.3-577-g6567380f, and the same happened as reported in Processing Queue https://discuss.pixls.us/t/processing-queue/6647:
After clicking the little icon that should move the image in the Editor to the processing queue, nothing happens, ie there is no number shown in the processing queue tab, and if I click that, RT crashes. It was the same with another raw file I tried, so it does not seem to be specific for the particular raw file I tried first.

I tried to identify the RT version via the prefs. When I hovered the mouse pointer over the little icon at bottom left, the ‘Preferences’ popup appeared, but the prefs did not open, not upon double-clicking either.

When I tried to exit RT by closing the window by clicking the x icon at top left, nothing happened, and I had to force quit.

So I think I go back to version 4 for now.

MacOS 10.11.6, MacPro early 2009, 2,66 GHz Quad-Core Intel Xeon processor, 24 GB RAM 1066MHz-DDR3 EEC.

Thank you for your work!
Hening

Though I thought this bug was fixed, in past this was caused by special characters in path or filename.
Can you please post the filename of input and output files with complete path?

Hi Ingo,

thank you for your comment. Uff, this may indeed be the solution.
The input file name is _DSC1338 copy.ARW, output _DSC1338 RT 12-50-15.tif - but the path contains both ö and ĂŒ, as can be seen in the attachment. I can not retry right now, I have trashed version 5.3-577 and will have to re-download tomorrow. So I will have to drag the input file to the Desktop. I had to do this in earlier versions of RT, but not in -gtk3.

Best regards - Hening

1 Like

Could be an OSX related regression. Maybe @HIRAM knows more.

Thanks for testing that, if you get a crash report that would be useful. I’ll try to crash my 10.11.6 system as well.

My 10.11.6 iMac core2duo is not experiencing any hang or crash when processing a CR2 with a folder containing ö and ĂŒ in that build using the queue


Hi Hiram and Heckflosse,
So today I re-installed 5.3-577, reproduced the crash, saved the crash log (attached). When I dragged the image file to the Desktop, thus avoiding the ö and ĂŒ in the Path, everything went fine!
I checked with a CR2 file as well, that made no difference, so uploading the raw file may be moot.
Best regards - and MANY thanks for your work with RT! A special thanks for the automatic CA removal, which has done wonders for me!
Hening.

There is no attachment

That is strange, because I am sure I did NOT forget to attach it - not this time. Maybe the forum software does not accept .rtf files as attachments? I try with a .zip this time.

Crash Log RawTherapee 05feb2018.rtf.zip (20.4 KB)

Here is a new build to try. Just tried to rebuild cairomm, and updated gtk+ and glibmm.
https://filebin.net/3xsk9qpq868ibky0/RawTherapee_OSX_10.9_64_5.3-602-ge6265cdf.zip
Let us know what errors you get. Also could you tell us what your system locale/language is set to. For example, I am using US-en United States/English.

Hi Hiram
there is no difference with the new build. Crash log attached. - The choice of language in RT is “Use system language”, and system language is English (no choice of US or UK in Mac). Mac system locale is Germany.

RT cras log 6feb2018.rtf.zip (20.4 KB)

I can’t open DMG. Do macOS builds have separate release and debug executables? Is Hening’s log from a debug executable?

@Morgan_Hardwood Just a “release” binary is included in the mac dmg. @hening’s macOS crash log is from a release binary.

So
with the file that is working on the desktop, place it into a new folder called földĂŒr or whatever, and see if it crashes when queuing.

Somehow I’d like to reproduce the crash.

Hi Hiram
I attach .zips of my log of today and 3 crash logs. RT crashed upon queuing if the raw was placed in a ‘földĂŒr’ folder on the Desktop.

RT log 07feb2018.rtf.zip (1.17 KB)

crash log 1.rtf.zip (15 KB)

crash log 2.rtf.zip (1.6 KB)

crash log 3.rtf.zip (20.4 KB)

Great news. Simply changing my system locale to Germany, I was able to generate this crash. It occurred after putting image in queue with the put-to-queue button, noticing no number in the queue icon, and finally this crashed thread when I clicked on the queue tab. Image resides on the desktop inside a folder named földĂŒr.

Thread 0 Crashed:: Dispatch queue: com.apple.main-thread
0   libcairomm-1.0.1.dylib        	0x0000000105153a60 Cairo::Context::set_source(Cairo::RefPtr<Cairo::Surface> const&, double, double) + 16
1   rawtherapee-bin               	0x00000001033eb77b ThumbBrowserEntryBase::draw(Cairo::RefPtr<Cairo::Context>) + 699
2   rawtherapee-bin               	0x00000001033e8551 ThumbBrowserBase::Internal::on_draw(Cairo::RefPtr<Cairo::Context> const&) + 369
3   libgtkmm-3.0.1.dylib          	0x0000000104374f2f Gtk::Widget_Class::draw_callback(_GtkWidget*, _cairo*) + 175
4   libgtk-3.0.dylib              	0x0000000104ab852e gtk_widget_draw_internal + 350 (gtkwidget.c:7021)
5   libgtk-3.0.dylib              	0x000000010488f655 gtk_container_propagate_draw + 501 (gtkcontainer.c:3840)
6   libgtk-3.0.dylib              	0x000000010488fd83 gtk_container_draw + 211 (gtkcontainer.c:3655)
7   libgtk-3.0.dylib              	0x000000010491bbd5 gtk_grid_render + 37 (gtkgrid.c:1715)
8   libgtk-3.0.dylib              	0x0000000104896b85 gtk_css_custom_gadget_draw + 37 (gtkcsscustomgadget.c:162)
9   libgtk-3.0.dylib              	0x000000010489c1db gtk_css_gadget_draw + 1659 (gtkcssgadget.c:877)
10  libgtk-3.0.dylib              	0x000000010491b041 gtk_grid_draw + 17 (gtkgrid.c:1724)
11  libgtkmm-3.0.1.dylib          	0x000000010437bf87 Gtk::Widget::on_draw(Cairo::RefPtr<Cairo::Context> const&) + 71
12  libgtkmm-3.0.1.dylib          	0x0000000104374f2f Gtk::Widget_Class::draw_callback(_GtkWidget*, _cairo*) + 175
13  libgtk-3.0.dylib              	0x0000000104ab852e gtk_widget_draw_internal + 350 (gtkwidget.c:7021)
14  libgtk-3.0.dylib              	0x000000010488f655 gtk_container_propagate_draw + 501 (gtkcontainer.c:3840)
15  libgtk-3.0.dylib              	0x000000010488fd83 gtk_container_draw + 211 (gtkcontainer.c:3655)
16  libgtk-3.0.dylib              	0x00000001048451b5 gtk_box_draw_contents + 37 (gtkbox.c:450)
17  libgtk-3.0.dylib              	0x0000000104896b85 gtk_css_custom_gadget_draw + 37 (gtkcsscustomgadget.c:162)
18  libgtk-3.0.dylib              	0x000000010489c1db gtk_css_gadget_draw + 1659 (gtkcssgadget.c:877)
19  libgtk-3.0.dylib              	0x0000000104844361 gtk_box_draw + 17 (gtkbox.c:459)
20  libgtkmm-3.0.1.dylib          	0x000000010437bf87 Gtk::Widget::on_draw(Cairo::RefPtr<Cairo::Context> const&) + 71
21  libgtkmm-3.0.1.dylib          	0x0000000104374f2f Gtk::Widget_Class::draw_callback(_GtkWidget*, _cairo*) + 175
22  libgtk-3.0.dylib              	0x0000000104ab852e gtk_widget_draw_internal + 350 (gtkwidget.c:7021)
23  libgtk-3.0.dylib              	0x000000010488f655 gtk_container_propagate_draw + 501 (gtkcontainer.c:3840)
24  libgtk-3.0.dylib              	0x0000000104997bf0 gtk_notebook_draw_stack + 64 (gtknotebook.c:2519)
25  libgtk-3.0.dylib              	0x0000000104896b85 gtk_css_custom_gadget_draw + 37 (gtkcsscustomgadget.c:162)
26  libgtk-3.0.dylib              	0x000000010489c1db gtk_css_gadget_draw + 1659 (gtkcssgadget.c:877)
27  libgtk-3.0.dylib              	0x00000001048476fc gtk_box_gadget_draw + 188 (gtkboxgadget.c:504)
28  libgtk-3.0.dylib              	0x000000010489c1db gtk_css_gadget_draw + 1659 (gtkcssgadget.c:877)
29  libgtk-3.0.dylib              	0x000000010499277e gtk_notebook_draw + 46 (gtknotebook.c:2532)
30  libgtkmm-3.0.1.dylib          	0x000000010437500b Gtk::Widget_Class::draw_callback(_GtkWidget*, _cairo*) + 395
31  libgtk-3.0.dylib              	0x0000000104ab852e gtk_widget_draw_internal + 350 (gtkwidget.c:7021)
32  libgtk-3.0.dylib              	0x000000010488f655 gtk_container_propagate_draw + 501 (gtkcontainer.c:3840)
33  libgtk-3.0.dylib              	0x000000010488fd83 gtk_container_draw + 211 (gtkcontainer.c:3655)
34  libgtk-3.0.dylib              	0x0000000104ad7a88 gtk_window_draw + 744
35  libgtkmm-3.0.1.dylib          	0x000000010437bf87 Gtk::Widget::on_draw(Cairo::RefPtr<Cairo::Context> const&) + 71
36  libgtkmm-3.0.1.dylib          	0x0000000104374f2f Gtk::Widget_Class::draw_callback(_GtkWidget*, _cairo*) + 175
37  libgtk-3.0.dylib              	0x0000000104ab852e gtk_widget_draw_internal + 350 (gtkwidget.c:7021)
38  libgtk-3.0.dylib              	0x0000000104ab9869 gtk_widget_render + 313 (gtkwidget.c:17494)
39  libgtk-3.0.dylib              	0x00000001049602e6 gtk_main_do_event + 1830 (gtkmain.c:1937)
40  libgdk-3.0.dylib              	0x0000000105007791 _gdk_event_emit + 49 (gdkevents.c:75)
41  libgdk-3.0.dylib              	0x000000010501d1c6 _gdk_window_process_updates_recurse_helper + 326
42  libgdk-3.0.dylib              	0x000000010502d84f -[GdkQuartzView drawRect:] + 319 (GdkQuartzView.c:641)
43  com.apple.AppKit              	0x00007fff771bdf99 -[NSView _drawRect:clip:] + 2276
44  com.apple.AppKit              	0x00007fff7720df2f -[NSView _recursiveDisplayAllDirtyWithLockFocus:visRect:] + 1753
45  com.apple.AppKit              	0x00007fff771bbad2 -[NSView _recursiveDisplayRectIfNeededIgnoringOpacity:isVisibleRect:rectIsVisibleRectForView:topView:] + 837
46  com.apple.AppKit              	0x00007fff771bc6d1 -[NSView _recursiveDisplayRectIfNeededIgnoringOpacity:isVisibleRect:rectIsVisibleRectForView:topView:] + 3908
47  com.apple.AppKit              	0x00007fff771bb2af -[NSThemeFrame _recursiveDisplayRectIfNeededIgnoringOpacity:isVisibleRect:rectIsVisibleRectForView:topView:] + 334
48  com.apple.AppKit              	0x00007fff771b96d8 -[NSView _displayRectIgnoringOpacity:isVisibleRect:rectIsVisibleRectForView:] + 2452
49  com.apple.AppKit              	0x00007fff771b4fca -[NSView displayIfNeeded] + 1748
50  com.apple.AppKit              	0x00007fff771b48db -[NSWindow displayIfNeeded] + 230
51  com.apple.AppKit              	0x00007fff77914cb4 ___NSWindowGetDisplayCycleObserver_block_invoke.6228 + 277
52  com.apple.AppKit              	0x00007fff771b43b9 __37+[NSDisplayCycle currentDisplayCycle]_block_invoke + 454
53  com.apple.QuartzCore          	0x00007fff7f459cc6 CA::Transaction::run_commit_handlers(CATransactionPhase) + 46
54  com.apple.QuartzCore          	0x00007fff7f5638ac CA::Context::commit_transaction(CA::Transaction*) + 160
55  com.apple.QuartzCore          	0x00007fff7f4587a1 CA::Transaction::commit() + 475
56  com.apple.AppKit              	0x00007fff774978b1 __37+[NSDisplayCycle currentDisplayCycle]_block_invoke.31 + 323
57  com.apple.CoreFoundation      	0x00007fff7958ede7 __CFRUNLOOP_IS_CALLING_OUT_TO_AN_OBSERVER_CALLBACK_FUNCTION__ + 23
58  com.apple.CoreFoundation      	0x00007fff7958ed57 __CFRunLoopDoObservers + 391
59  com.apple.CoreFoundation      	0x00007fff7956fb09 __CFRunLoopRun + 873
60  com.apple.CoreFoundation      	0x00007fff7956f544 CFRunLoopRunSpecific + 420
61  com.apple.HIToolbox           	0x00007fff78aceebc RunCurrentEventLoopInMode + 240
62  com.apple.HIToolbox           	0x00007fff78acebf9 ReceiveNextEventCommon + 184
63  com.apple.HIToolbox           	0x00007fff78aceb26 _BlockUntilNextEventMatchingListInModeWithFilter + 71
64  com.apple.AppKit              	0x00007fff77065a54 _DPSNextEvent + 1120
65  com.apple.AppKit              	0x00007fff777e17ee -[NSApplication(NSEvent) _nextEventMatchingEventMask:untilDate:inMode:dequeue:] + 2796
66  libgdk-3.0.dylib              	0x0000000105034cec poll_func + 172 (gdkeventloop-quartz.c:742)
67  libglib-2.0.0.dylib           	0x0000000104194f7f g_main_context_iterate + 340
68  libglib-2.0.0.dylib           	0x000000010419522a g_main_loop_run + 207
69  libgtk-3.0.dylib              	0x000000010495fa4a gtk_main + 74 (gtkmain.c:1323)
70  libgtkmm-3.0.1.dylib          	0x00000001042f7abd Gtk::Main::run(Gtk::Window&) + 253
71  rawtherapee-bin               	0x0000000103325796 main + 5158
72  libdyld.dylib                 	0x00007fff8f139235 start + 1

I’ll see if I can get any data from a debug build (and open an issue on GH).

@heckflosse @Morgan_Hardwood

This issue seems similar. In @hening’s case, we have successfully processed queues of images from folders with international characters like ö and ĂŒ. At this point however changing the system region from United States to Germany causes a different crash upon switching to queue.

In a previous issue

we added this to the executable loader:

# Prevent crash when directory name contains special characters
AppleLocale=\`defaults read -g AppleLocale\`
export LANG=${AppleLocale%@*}.UTF-8

To fix another ö/ĂŒ crash related to the language set.

Now that those errors are fixed, I notice the new crash involving a cairomm call when I switch my system region to Germany from US (and use ö’s and ĂŒâ€™s).

As you mentioned me: Is there anything I can do to help fixing the issue?

@heckflosse Do you think en_DE is being handled as normally as en_US in RT, for instance in the code above?

Wait, that rings a bell with me. There’s new code here, that overwrites LANG without the .UTF-8 suffix. If that was a problem before, it is again now.

HTH,
Flössie
