Yet another G'MIC challenge - Extracting shape with error margin

As I found a very interesting need over at PDN forum, the challenge is to extract shapes with error margins. Some theory on solving this problem is use areas, gradient angle, inpainting to extract shapes. But, that may or may not be enough and especially with large error margin.

The challenge is to extract shapes using this image:

My attempt

repeat $! l[$>]
to_rgb
rgb2hsv channels 0 tones 2
k.
erode 5
dilate 5
+area_fg 0,0
f. i>ia?0:i
store. area
+gradient2rgb ,
+f. i>0
compose_channels. +
f. i>0
negate.
inpaint_pde.. .
rm.
rv +blend shapemedian0
blend[^-1] shapeaverage0
blend average
n. 0,255
rgb2hsl sh. 1 f. i>0?1 rm. hsl2rgb
$area
n. 0,360
+f. i0#1>0?1 . a[^0] c hsv2rgb. blend interpolation,.5
endl done

Result:
